Fancybox Integration¶

Fancybox is a popular JavaScript application for displaying images on web pages. It is similar to LightBox 2, but more feature-rich and probably more stable. Since Fancybox is only free for non-commercial usage, there is no plugin for Sphinx, but for a non-commercial and non-profit site like this, adding it is possible, free-of-charge.

For this purpose, I created a modified version of the sphinxcontrib-images plugin, that only supports Lightbox 2 out-of-the-box.

For local extensions in a Sphinx project, it’s best practice to create a folder in the source directory. I named mine .extension but you can choose any name you want. I placed all the sphinxcontrib-images stuff into this folder and then added the following to my conf.py:

import os
import sys
from pathlib import Path
sys.path.append(str(Path('.extension').resolve()))

This adds the .extension directory to the search path so plugins can be loaded from there.

Note

Make sure to uninstall any version of the sphinxcontrib-images plugins you may have installed via pip or other means.

Installing the FancyBox script and CSS¶

Basically, there are two methods. One involves modifying your HTML templates and using FancyBox via its CDN. The method is described in the FancyBox documentation. Refer to the Sphinx templating documentation to learn how to override your page templates in order to add the required scripts and style sheets.

The second method is a completely local one and does not require to use template overrides nor a need to download the scripts and stylesheets from a CDN. Download the FancyBox distribution from GitHub and extract the two relevant files to your _static content folder.

fancybox.umd.js goes to _static/js
fancybox.css goes to _static/css

Next, create a simple JavaScript file and name it footer.js.

footer.js¶

Fancybox.bind("[data-fancybox]", {
  // Your custom options
});

Copy this file to _static/js just where all the other custom scripts are (right now, only fancybox.umd.js should be there)

The final step is to modify conf.py to add both the style sheet and the two scripts to your site. In order to do so, you must add them to html_css_files and html_js_files respectively.

conf.py¶

html_css_files = [
    [...],
    'css/site.css',
    'css/fancybox.css'
]

html_js_files = [
    'js/fancybox.umd.js',
    'js/footer.js'
]

In order to use it with your local sphinxcontrib-images extension you also have multiple options. The simplest one is to modify .extension/sphinxcontrib_images_lightbox2_lightbox2.py and do the following:

Remove everything from STATIC_FILES. This adds the LightBox 2 scripts and style sheets which are no longer needed. You already have the FancyBox stuff added. Leaving the LightBox 2 files there won’t hurt, but it will just be a waste, so remove it.
Replace the occurrence of data-lightbox with data-fancybox. Alternatively, it might work to bind FancyBox to data-lightbox (modify the footer.js you have created before), but there might be side effects.

Some examples, a simple gallery using only CSS and thumbnail directives, provided by the sphinxcontrib-images plugin

More examples, left and right aligned with text flow¶

A test image right aligned with border forced

Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat. Duis aute irure dolor in reprehenderit in voluptate velit esse cillum dolore eu fugiat nulla pariatur. Excepteur sint occaecat cupidatat non proident, sunt in culpa qui officia deserunt mollit anim id est laborum.

Centered Image with percentage width¶

A test image with a longer comment centered. © NASA

The same image with a forced pixel border¶

And again the same without any colored caption¶

A test image with a longer comment centered. Width set to 90% © NASA

And finally, the image alone. No caption¶
